FIuidized Bed Heating Furnace

The fluidized bed heater utilizes the principle ofconvective heat transfer, where hotgas causesmaterial particles to suspend andfluidize forefficient heating. The core technology lies in the gasdistributor plate, which ensures uniform hot gas flowthrough the material bed for full contact.
Widely used in silicon-carbon anode materials, chemical industry, renewable energy, and otherfields. Suitable for drying, calcining, and preheatingof granular and powdery materials.

The fluidized bed heater utilizes the principle ofconvective heat transfer, where hotgas causesmaterial particles to suspend andfluidize forefficient heating. The core technology lies in the gasdistributor plate, which ensures uniform hot gas flowthrough the material bed for full contact.
Widely used in silicon-carbon anode materials, chemical industry, renewable energy, and otherfields. Suitable for drying, calcining, and preheatingof granular and powdery materials.

High heat transfer efficiency: Large gas-solidcontact area, high heat efficiency.
Temperature uniformity: Intense mixing ensures no localized overheating.
Energy saving and consumption reduction: Application of special insulation materials, compatible with waste heat recovery systems.
Easy operation: Compact structure; supports automated production.

High heat transfer efficiency: Large gas-solidcontact area, high heat efficiency.
Temperature uniformity: Intense mixing ensures no localized overheating.
Energy saving and consumption reduction: Application of special insulation materials, compatible with waste heat recovery systems.
Easy operation: Compact structure; supports automated production.

Items	Furnace Parameters
Product Size	Customizable / Diameter: 100-1800 mm / Height: 0.5-15 m
Heating Method	Resistance heating (resistance wire, silicon carbide rods, molybdenum disilicide rods, etc.)
Operating Temperature	Ambient ~1300°C
Temperature Control Accuracy	±1°C~5°C
Power Range	Customizable
Heat Loss	<260 kcal/m2.hr
Sheet Metal Material	Carbon steel, stainless steel, or special alloy
